Quote:
Anyone know which size Tekota is needed to fit 10 colors of 18lb lead and backing? By comparing specs it appears the 600 has about the same capacity as the Daiwa lc47 reels – is that right?
Yes it’s about the same line capacity.
TEK600LC = 20 lb / 300 yards
DiawaLC47 = 20 lb / 280 yards
So the big question is how much backing should I put on reel and still have my TEK600LC be calibrated? Keep in mind your line counter reel doesn’t actually measure feet – it measures revolutions of your spool. So if your reel is only half full in will measure more like 14-16 inches versus 12 inches. A fully spooled line counter reel usually measures correctly – 12 inches per revolution. You can calibrate your line counter reel by measuring out 100 feet in your yard with a tape measure and then pull your line off your line counter reel to that 100 foot spot and see what your line counter actually reads. Add or take away line and measure it again until it reads accurately.
OK – now back to how much backing you will need:
The easiest and most accurate way to do this IF you have two reels is to put the lead core line on first and then add your mono backing until your spool is full and then go calibrate it before you cut your mono line. Once your reel is calibrated – now move that line to your other line counter reel so your backing goes on first followed by the lead core line.
If you only have one reel it get’s a little trickier. In order to figure out how much backing you need – there are 3 things you need to consider:
1. the amount of lead core line you are wishing to add
2. the line capacity of your reel
3. and line diameters
Now let’s do the math:
1. you are wishing to add 100 yards of lead core line
2. the TEK600LC line capacity = 20 lb / 300 yards (keep in mind this capacity is figured for mono).
3. the line diameter for 20 lb. mono = .018
3. the line diameter for 18 lb. regular lead core = .025
The difference is .07 or 39%
Now add 39% to your lead core line: 100 yards * 39% = 139 yards
Minus that from your TEKLC600 line counter reel capacity: 300 – 139 = 161 yards
Add 161 yards of 20 lb mono backing and then add your 10 colors of lead core.
